Part Number | Description |
18-11010 |
Hose 3/4"ID X 4-1/4" 3-Ply Silicone |
27-31602 |
Tube,Turbo Oil Return (Upper 1/2) |
19-31401 |
V-Clamp (K26 Pattern Flange) |
12-00314 |
CS,HX HD 3/8-16 X 1-1/2" Grade 5 |
11-31011 |
Gasket,Exhaust Outlet |
11-31012 |
Gasket,Turbo Oil Return |
11-31031 |
Gasket,Turbo Oil Return |
12-00414 |
CS,HX HD 7/16-14 X 1-1/2" |
24-00000 |
OIL FILTER 4239-439-4276-445-6414-668 (12 PER CASE) |
10-31506 |
Flange,K26 Turbo Pattern Wet Exhaust |
11-11023 |
Gasket,Expansion Tank-to-Exhaust Manifold |
11-11043 |
Gasket,Heat Exchanger / Keel Cooler Outlet connection |
12-00712 |
CS,HX HD M8x1.25 X 25mm Grade 8.8 DIN Code 931-ZP |
12-00714 |
CS,HX HD M8x1.25 X 40mm Grade 8.8 DIN Code 933-ZP |
11-31401 |
Gasket,K26 Turbocharger Mounting (with Coolant Passage Penetrations) |
15-00302 |
Lock Washer,Helical 3/8" |
13-00814 |
Stud M10x1.5 X 30mm (42mm LOA) Grade 10.9 DIN Code 939-10 |
11-11611 |
Gasket,Square Coolant Port - 80 Durometer SBR (Red) - see Application Comments |
24-21000 |
Air Filter 8"OD X 8-3/4" (10-3/4"LOA)- 4-1/8"OD X 2" Outlet |
14-00817 |
Hex Nut M10x1.5 S/S (316) (17mm Hex) DIN Code 934-A4 |
11-30013 |
Gasket,Exhaust Manifold Adapter Mtg |
21-52800 |
M.CONN.STL. 3/8NPT X 3/8-37T |
R41285 |
Tube Adapter,O-Ring Slip-Fit 3/4"ID X 1/2NPT |
16-01000 |
O-Ring 3/4"ID X 3/32" Nitrile |
R43928 |
ADAPTER,TURBO OIL SUPPLY |
21-10001 |
Drain Cock,Brass 1/8NPT (Counterclockwise-to-Open) |
AR67942 |
CRANKSHAFT SEAL,FRONT |
18-21020 |
Hump Hose 4-1/8"ID X 2"ID X 4-3/4"LOA w/o Vent Hole |
27-31622 |
TUBE ASSY,TURBO OIL SUPPLY L-M668 W/SINGLE HORIZONTAL OIL FILTER |
27-21010 |
Tube Assembly,Air Intake 4 / 6-Cyl Deere |
