Part Number | Description |
RE507959 |
INJECTION PUMP,HPCR 1064/1066 CORE CREDIT VALUE $400.00) |
27-59512 |
Double Wall Injection Line #1 & #2 HPCR (Marked #1) |
27-59534 |
Double Wall Injection Line #3 & #4 HPCR (Marked #2) |
27-59656 |
Double Wall Injection Line #5 & #6 HPCR (MARKED #3) HPCR |
27-59504 |
Tube Assy,HPCR Manifold Inlet #1 Double Wall (Marked #4) |
27-59505 |
Tube Assy,HPCR Manifold Inlet #2 Double Wall (Marked #5) |
21-59517 |
Banjo Bolt 1/8BSPP X 3/4" |
21-59518 |
Banjo Bolt, 1/8BSPP X 1-1/4" Double Length |
27-59507 |
Tube,Fuel Return to Alarm Tank,Lower |
27-59508 |
Tube,Fuel Return to Alarm Tank |
27-59509 |
TUBE,FUEL RETURN TO ALARM TANK 1/8BSPP BANJO X 6mm STANDPIPE |
19M8162 |
CS,HX HD FLANGED M10x1.5 X 40mm Grade 10.9 DIN Code 6921-10ZY |
27-19611 |
Tube Assy,Turbo Coolant Supply |
27-59637 |
Tube Assy,Final Fuel Filter Outlet - HPCR System with Double Wall Fuel Lines |
21-59519 |
EL.45,SWIVEL,STL. 3/8-37T |
18-59512 |
Hose Assy 1/4"ID X 12" 8mm90 DKO Swivel X 8mm Light Standpipe S/S-TFE - see Application Comments |
18-59513 |
Hose Assy 1/4"ID X 13" 8mm90 DKO Swivel X 3/8FMS S/S-TFE |
27-39613 |
TUBE ASSY,TURBO OIL SUPPLY (WITH DUPLEX OIL FILTER) |
18-29601 |
HOSE 2-3/4"ID X 3" 3 PLY SILICONE |
18-11010 |
Hose 3/4"ID X 4-1/4" 3-Ply Silicone |
22-49509 |
Engine Wire Harness CAN-BUS & HPCR Controller M1064H - M1066H |
R114193 |
BUSHING |
111996470 |
GASKET,ROCKER ARM COVER 673 TIER 2 & 3 |
RE516228 |
PISTON & LINER KIT (Piston Marked RE507758) |
R502755 |
PISTON PIN |
RE505941 |
CRANKSHAFT PULLEY/DAMPER 188mmOD |
RE503664 |
IDLER SHAFT & BEARING HOUSING ASSY HD - IRON (HSG MARKED R502014) |
RE519730 |
FUEL INJECTOR,ELECTRONIC UNIT TYPE M1064H @ 1500RPM & L-M1066H - NL1066H4 ALL |
R515044 |
NUT,INJECTION LINE CONNECTION |
33-81013 |
Hydrolastic Mount 500 LBS |
33-81014 |
Hydrolastic Mount 600LBS |
11-31011 |
Gasket,Exhaust Outlet |
22-40904 |
Switch,Temperature 205F N.O./ N.C. Isolated Ground 1/2NPT 3ea #8-32 Terminals |
18-59616 |
HOSE ASSY 5/16"ID X 34" 3/8FMS X 3/8FMS USCG A-1 SAE J1942 ABS |
18-59617 |
HOSE ASSY 3/16"ID X 32" 1/4FMS X 1/4FMS USCG A-1 SAE J1942 ABS |
22-41079 |
Solenoid 24VDC 85A N.O. Isolated Ground |
RE516335 |
VALVE,PRESSURE RELIEF HPCR |
35-12500 |
Thermostat 169F / 76C 52mm OD S/S (Rubber Poppet Seat) |
R521458 |
BOLT,ROCKER ARM RETAINING (TAPPED M8x1.25) |
22-40536 |
Switch,Pressure 9PSI N.O./ N.C. Isolated Ground 1/8NPT |
RE509093 |
WIRE HARNESS ASSY,HPCR FUEL INJECTOR CIRCUIT 12-PIN 6-CYL |
R502512 |
SLEEVE |
R114194 |
SHAFT |
RE508489 |
GEAR |
R504843 |
SHAFT |
18-62520 |
Hose 1-3/4"ID X 3-3/4" 3-Ply Silcone |
37-16812 |
Bonnet Assembly 25 GPM Set Point 2" Flow Switch - see Application Comments |
R522334 |
GASKET,THERMOSTAT HOUSING |
T20168 |
WASHER |
22-40941 |
Switch,Temperature 195F N.O./ N.C. Isolated Ground 3/8NPT (3ea #8-32 Terminals) |
24-21000 |
Air Filter 8"OD X 8-3/4" (10-3/4"LOA)- 4-1/8"OD X 2" Outlet |
R528387 |
CAPSCREW HEX HEAD FLANGED 1/2-13 X 3-3/4" SPECIAL |
RE546906 |
COOLANT PUMP,CAST IRON (HIGH FLOW) 668 - 1064H - 1066 |
R516140 |
STRAP |
22-40963 |
Switch,Pressure 15PSI N.O./ N.C. 1/8NPT 10A Contacts |
R534091 |
CAPSCREW HEX HEAD FLANGED 1/2-13 X 5.43" SPECIAL |
R522314 |
GASKET,EXHAUST MANIFOLD |
R523076 |
O-RING |
RE553419 |
CYLINDER HEAD ASSEMBLY L-M1066H AND NL1066H4 See Application Comments |
35-11000 |
Thermostat 180F / 82C 52mm OD S/S (Rubber Poppet Seat) |
35-11004 |
Clamp,Dual Thermostat Retainer |
24-51008 |
Element,Fuel filter 2 Micron with Plastic Drain Valve 6" L-M1066H HPCR System |
R54114 |
SNAP RING 1.80"OD (FREE) X 0.062" |
R28811 |
FLYWHEEL RING GEAR SAE#11-1/2 & SAE#14 (129 TEETH) |
DZ100057 |
OIL PUMP ASSEMBLY 4.5 & 6.8 POWERTECH TIER 1 & 2 |
R516682 |
O-RING |
RE560754 |
OIL COOLER |
18-21003 |
Hump Hose 4" X 2-3/4" X 4"LOA with 5/8"ID Vent Hole |
22-40710 |
Relay SPDT 24VDC 20A (Suppression w/ Resistor) |
22-42802 |
Sender,Temperature 250F Isolated Ground 1/2NPT |
22-42803 |
Sender,Pressure 0-80 PSI Isolated Ground 1/8NPT (Marked 32/1) |
16-15006 |
O-Ring 1-1/8"ID X 3/16" Nitrile |
24-20029 |
Element, Crankase Breather Filter (Low restriction, Aluminum Open ) CCV4500 |
DZ111102 |
PUSH ROD |
DZ117587 |
FUEL LIFT PUMP ASSY (W/O FITTINGS) 1064-1066 HPCR SYSTEMS |
DZ118906 |
CAMSHAFT ASSEMBLY |
RE540289 |
DOUBLE WALLED FUEL LINE #2 |
16-14804 |
O-Ring 2"ID X 1/8" Nitrile |
24-05701 |
Oil Filter L-M-NL6108 & All NLI Models built with Integrated Duplex Oil Filter (12ea per Case) |
25-15705 |
End Cover,Raw Water Pump 4-Hole "Lugger / Northern Lights" (127mmOD) |
25-15706 |
Wear Plate |
18-75701 |
Hose Assy 1/2"ID X 32" 1/2FMS X 1/2FMS |
15-55701 |
SEALING WASHER,BONDED 1/8BSPP |
18-26002 |
Hose 2"ID X 3-3/4" 4-Ply Silicone J20R1 Class A To 350F |
21-00056 |
F.ADAPTER,STL. 1/4NPT X M14x1.5 (1-3/8"LOA) |
RE515636 |
RESTRICTOR |
22-40277 |
Alternator 24V/75A Isolated Ground Large Frame (with Adjustable Regulator) |
18-70004 |
HOSE ASSY 3/8"ID X 7" 3/8FMS X 3/8FMS S/S-TFE |
22-40357 |
Switch,Pressure 25PSI N.O./ N.C. 10A Contacts 1/8NPT |
18-55405 |
Hose Assy 1/4"ID X 9" (9.5"LOA) 1/4FMS X 1/4FMS S/S-TFE |
R120467 |
Elbow 90 Degree 3/4"HB (w/o O-Ring) Vent Outlet |
R135918 |
CS,HX HD FLANGED M12x1.75 X 40mm GRADE 10.9 |
22-40377 |
Relay 24VDC 6A SPDT DIN Rail Mtg |
16-19503 |
O-Ring 4-1/4"ID X 3/32" Nitrile |
32-00005 |
Cotter Pin S/S 1/8" X 1-1/4" ANSI B18.8.1-R1977 |
19-01012 |
Hose Clamp #12 Extended Band S/S (316) 7/8" Min X 1-1/4" Max |
19-01028 |
Hose Clamp #28 Extended Band S/S (316) 1-5/16" Min X 2-1/4" Max |
15-70007 |
Snubbing Washer S/S (304) 0.375"ID X 0.875"OD X 0.060" |
15-19504 |
Washer,Neoprene 0.390"ID X 0.865"OD X 0.062" |
21-12013 |
Filler Cap 7PSI Double Seal Coolant Recovery Type |
16-00005 |
O-Ring 11.3mmID X 2.2mm 90 Durometer Nitrile (ISO 6149 Port) |
16-09502 |
O-RING 0.614"ID X 0.070" 90 DUROMETER NITRILE (SAE J515 TYPE CH) |
20-49504 |
Thermostat & Probe Y-Harness Assembly 240VAC 80F On / 100F Off (1/2" NPT) |
RE65908 |
ROD BEARING,STD |
27-59604 |
INJECTION LINE #4 DOUBLE WALL (MARKED #3) |
22-40408 |
Timer Module 24VDC 20A N.O. 20 Second Delay (One-Shot Operation) |
24-28602 |
Element,Air Filter (Foam 10 PPI Reticulated Polyether) M773 |
R61467 |
O-RING, CAMSHAFT |
22-40914 |
Switch,Temperature 240F N.O./ N.C. Isolated Ground 3/8NPT |
22-40438 |
Speed Switch 2-Element Electric SS40A (Programming Req'd) |
RE65165 |
MAIN BEARING KIT,STD |
RE65168 |
THRUST BEARING KIT,STD |
22-40439 |
Speed Sensor 3/4-16 X 2-1/4" (Metri-Pak 150.2 Connector) |
RE505501 |
VALVE,OIL PRESSURE REGULATING |
R501124 |
BOLT, CONNECTING ROD |
14M7066 |
NUT |
25-19519 |
Raw Water Pump |
27-19510 |
Tube,Heat Exchanger Inlet S/S (316L) 2"HB X 2"HB L-M1064H & L-M1066H |
19-01048 |
Hose Clamp #48 Extended Band S/S (316) 2-9/16" Min X 3-1/2" Max |
19M7811 |
CS,HX HD FLANGED M10x1.5 X 90mm GRADE 10.9 DIN CODE 6921-10ZY |
19-01032 |
Hose Clamp #32 Extended Band S/S (316) 1-9/16" Min X 2-1/2" Max |
27-59608 |
TUBE ASSY,FUEL LIFT PUMP OUTLET |
27-19511 |
Tube,Coolant Pump Inlet (4-Valve SWAC Models) |
21-09702 |
M.CONN.BRS. 1/4NPT X 3/8" Tube Comp (5/8-24 Vibra-Lok Body Only) |
RE167207 |
SENSOR,OIL & FUEL PRESSURE |
27-19512 |
Tube Assy,Coolant Bypass |
25-19526 |
Shaft Seal (Carbon / Ceramic) |
RE57604 |
CRANKSHAFT DAMPER,VISCOUS L1166A - M1166AR - M1166AMCA |
RE52722 |
SENSOR,COOLANT TEMPERATURE M14x1.5 - Probe = 7.8mmOD x 14mm (from thread stop) Metri-Pak 150.2 Connector - see Application Comments |
R517237 |
WASHER |
R516648 |
CS,HX HD M20x2.5 X 70mm GRADE 12.9 UNPLATED |
R123565 |
FOLLOWER |
RE61812 |
SENSOR,AIR INLET TEMPERATURE M14x1.5 - Probe = 7.8mmOD x 14mm (from thread stop) Metri-Pak 150.2 Connector -see Application Comments |
30-30027 |
Turbocharger K27 |
RE519144 |
Speed Sensor M20x1.5 X 36mm Probe Length (Metri-Pak 150.2 Connector) |
27-59503 |
Tube Assy,Fuel Return |
21-09703 |
Sealing Sleeve 3/8"OD Tube Viton (Red Stripe) |
29-09602 |
Gasket Set,Engine Overhaul L-M1066H (Non-Returnable If Opened) |
27-39607 |
Tube Assy,Turbo Coolant Return |
RE518097 |
AUTOMATIC BELT TENSIONER ASSEMBLY (see Application Comments) |
27-19517 |
Tube,Flow Switch Inlet S/S 2"HB X 9-1/2" (1-7/64" Offset S-Bend) |
R114082 |
BUSHING |
18-09604 |
Hose Assy 1/2"ID X 31" 5/8 O-R Face Seal X 5/8 O-R Face Seal |
18-09605 |
Hose Assy 1/2"ID X 34" 5/8 O-R Face Seal 90 X 5/8 O-R Face Seal |
R518210 |
SPACER,TENSIONER MTG |
18-29502 |
HOSE 2"ID X 3-1/2" 4 PLY SILICONE |
